PTO Shaft V12 1.3/4-6 Shear Bolt 1.3/4-6 Long Evo

Qty:

Add to cart

LĂ€gg i kundvagnen

• Info
• Stock status

  Product IDT831521E

  ManufacturerBENZI DI TERLIZZI

  Characteristics

  - Type: V12
  - clutch bolt 3500 Nm
  - end of the fork on the tractor: 1.3/4"-6Z collar lock
  - fork machinery head: 1.3/4"-6Z wedge bolt lock
  - output 540 rpm, 121 kW / 165 hp / 2145 Nm
  - power 1000 rpm 188 kW / 255 hp / 1795 Nm
  - max. static load for the pipe: 6000 Nm
  - length: L 1210 mm, M 1560 min., M max. 2165 mm
  - mesh: A/B: 50 x 118 mm
  - inner tube: 61 mm star A, B 47 mm, D 4.5 mm
  - outer tube: A star 71.5 mm B 57.5 mm, D 5 mm
  - applications guidance large trailers, excavators, splitters, peat machines, etc..
  - see dimensional drawing references of the image
  - values defined by a constant load, a 5° angle, and 1000 operating hours


  Additional information:
  - Evolution axles safety chains with the requirements of the machinery directive guards, play-free Kartiopulttilukitus career axles, up to 50 h service intervals, lattice lubrication network to get the axle in place, lubrication nipple for lubrication tubes metal grease for lubrication suojuslaakerien, hardened tubes, heavy fork arms
  - NOTE! before use
