  Product IDMWP56003

  ManufacturerMETAL WORK

  Characteristics

  Syntesi filter regulator SY1:
  - filter regulator combines filtering, condensate separation, and pressure regulation in a single unit
  - RMSA: condensate is drained in pressureless state, or by pressing the valve upwards manually
  - lockable handle
  - thread G 1/4"
  - pressure gauge/vent G 1/8"
  - tank volume 30 cm³
  - filtration grade 20 micron (standard ISO8573-1: 4.7.4)
  - max. operating pressure 15 bar
  - max. flow at 6.3 bar (pressure drop 0.5 bar) 800 Nl/min
  - max. flow at 6.3 bar (pressure drop 1 bar) 2000 Nl/min
  - max. flow (safety valve) at 6.3 bar 70 Nl/min
  - flow (vent) at 6.3 bar 500 Nl/min
  - operating temperature -10...+50 °C
  - media: compressed air or inert gas
  - mounting orientation vertical
  - mounting screws M4
  - weight 239 g

  Syntesi coalescing filter SY1:
  - efficiently separates liquid and solid particles from compressed air
  - RMSA: condensate is drained in pressureless state, or by pressing the valve upwards manually
  - thread G 1/4"
  - vent thread G 1/8"
  - tank volume 15 cm³
  - filtration grade 0.01 (standard ISO8573-1: 1.7.2)
  - max. operating pressure 15 bar
  - max. flow control at 6.3 bar 460 Nl/min
  - flow (vent) at 6.3 bar 500 Nl/min
  - operating temperature -10...+50 °C
  - mounting orientation vertical
  - mounting screws M4
  - weight 189 g
