Filterregulator 1/2 Sy2 Fr-D-Ac Breathing

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product IDMWP56002

  ManufacturerMETAL WORK

  Characteristics

  Syntesi filter regulator SY2:
  - filter regulator combines filtering, condensate separation, and pressure regulation in a single unit
  - RMSA: condensate is drained when pressure is released, or by manually pushing the valve up
  - lockable knob
  - thread G 1/2"
  - connection for pressure gauge or venting G 1/4"
  - tank volume 70 cm³
  - filtration grade 20 microns (standard ISO8573-1: 4.7.4)
  - max. working pressure 13 bar
  - max. flow at 6.3 bar (pressure drop 0.5 bar) 4300 Nl/min
  - max. flow at 6.3 bar (pressure drop 1 bar) 7200 Nl/min
  - maximum flow (safety valve) at 6.3 bar 100 Nl/min
  - flow (venting) at 6.3 bar 1400 Nl/min
  - operating temperature -10...+50 °C
  - media: compressed air or inert gas
  - vertical mounting position
  - fixing screws M5
  - weight 596 g

  Syntesi dehydrator SY2:
  - effectively separates liquid and solid particles from compressed air
  - RMSA: condensate is drained when pressure is released, or by manually pushing the valve up
  - thread G 1/2"
  - vent thread G 1/4"
  - tank volume 40 cm³
  - filtration grade 0.01 (standard ISO8573-1: 1.7.2)
  - max. working pressure 13 bar
  - max. flow control at 6.3 bar 620 Nl/min
  - flow (venting) at 6.3 bar 1500 Nl/min
  - operating temperature -10...+50 °C
  - vertical mounting position
  - fixing screws M5
  - weight 456 g

  Syntesi activated carbon filter SY2:
  - a filtration system with an activated carbon filter achieves the highest level of purification
  - filters out all impurities: oils, solvents, hydrocarbons, and unpleasant odors
  - RMSA: condensate is drained when pressure is released, or by manually pushing the valve up
  - filter cartridge lifespan 4000 h
  - thread G 1/2"
  - connection for pressure gauge or venting G 1/4"
  - filtration grade/residual oil at 20°C 0.003 mg/m³ (standard ISO8573-1: 1.7.1)
  - max. working pressure 13 bar
  - max. flow control at 6.3 bar 800 Nl/min
  - flow (venting) at 6.3 bar 1500 Nl/min
  - operating temperature -10...+50 °C
  - installation in any position
  - fixing screws M5
  - weight 456 g
