Selector valve 6/2, 3/8" 12V

Qty:

Add to cart

Add to cart

• Info
• Stock status

  Product IDFM2510

  ManufacturerAGRILIFE

  CharacteristicsMax. flow 40 l/min

  Electric 6/2 valve with the possibility to control additional functions with the same directional valve.
  Activate specific function by switching the solenoid valve.

  Technical specification:
  - voltage: 12 V
  - connections: 3/8" BSP
  - max. flow: 40 l/min
  - max. pressure: 310 bar
  - for hydraulic and electrical connection, see image

  Spare Parts / Accessories:
  - solenoid spare part FM2520
  - matching coupling FM2524, type DIN 93650, ISO 4400
