Changeover Relay 4-Pole 24V 20A

Qty:

Add to cart

LĂ€gg i kundvagnen

• Info
• Stock status

  Product IDST050101

  Manufacturer

  Characteristics

  - 24 V / 20 A

  Explanation:
  - 85 = coil ground
  - 86 = coil control voltage
  - 30 = main current
  - 87 = output from relay when voltage is supplied to coil
  - 87A = output from relay when voltage is not supplied to coil

  General connection instructions:
  30 = main current
  31, 85 = ground
  49, X = flasher relay input
  49A, L = flasher relay output
  86 = control voltage
  87 = relay contact in breaker and switch, input
  87A = first output
  C = signal lamp (dashboard)
  C2 = second signal lamp
  C3 = third signal lamp
  P = signal light
