  Product ID87000826

  Manufacturer

  CharacteristicsAxis-Ø (mm): 16
  Displacement (cm³): 31.6

  Motor BMM 32, once again a reliable and compact solution for hydraulic applications.

  Pressure differential (bar): 100
  Max torque (Nm): 40
  Comparison number S.A.M. Hydraulics: BGM S032 SP1
  Comparison number Danfoss: 151G0006
  L (mm): 115
  Max speed (rpm): 630
  Connection A-B (BSP): 3/8"
  Input pressure (bar): 175
  Connection: G 3/8"
  Shaft-Ø (mm): 16
  Volume (cm³): 31.6
  Max performance (kW): 2.4
  Max volume flow (l/min): 20
  Leak oil connection: G 1/8"
  L1 (mm): 13.5
