Hydraulic hose 2Sn-1/2 275Bar En 853

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product ID2SN08T

  ManufacturerVITILLO

  Characteristics

  - Vitillo Tekno/2SN hydraulic hose
  - EN 853 2 SN - SAE 100 R2AT
  - reinforcement with 2 braided steel wire inserts
  - internally oil resistant synthetic rubber
  - externally weather and oil resistant synthetic rubber
  - operating temperature -40...+100 °C
  - nominal size -08
  - hose DN 12
  - inner Ø 1/2"
  - inner Ø 12.8 mm
  - outer Ø 21.9 mm
  - working pressure 275 bar
  - burst pressure 1100 bar
  - bending radius 180 mm
  - weight 0.74 kg/m

  Approved fluids:
  - mineral oils
  - vegetable and rapeseed oils
  - glycol and polyglycol based oils
  - synthetic ester based oils
  - oil-in-water emulsion
  - water
